Quick Details

  • Application: Laser Engraving
  • Condition: New
  • Engraving Area: 80 mm x 80 mm (3.1 in. x 3.1 in.)
  • Engraving Speed: 24 mm/sec (0.94 in./sec) (Vector)
  • CNC or Not: Yes
  • Applicable Material: Metal
  • Graphic Format Supported: BMP, PLT
  • Place of Origin: Beijing, China (Mainland)
  • Brand Name: SIC
  • Model Number: CNCR-ROL-MPX-90
  • Dimension(L*W*H): Maximum 100 mm (w) x 200 mm (l) x 40 mm (t)
  • Certification: CE
  • warranty: 2 years
  • Resolution: 529 dpi (High resolution), 353 dpi (Photo),
  • Printing Direction: Unidirectional printing or bidirectional printing
  • Printing Speed (Default): 50 mm/sec (1.9 in./sec) (Photo), 33 mm/sec (1.2 in./sec),
  • Power Requirements: AC 100V to 240V ±10% 50/60Hz, DC19V 1.6A
  • Weight: 10.8 kg (23.8 lb.)

Packaging & Delivery

Packaging Details carton for Roland Engraver Machine
Delivery Time within 10 working days


Features:

Roland MPX-90 desktop impact printer is a powerful personalization device for applications ranging from industrial making to jewlry engraving. With the ability to imprint both flat and curved surfaces across a wide range of materials, the MPX-90 is Roland's most versatile impact printer to date. The MPX-90 offers 2.5 times the imprinting power of previous models to create exceptionally sharp text, monograms, graphics and photo on metallic surfaces.
A new work table design allows you to mark items of virtually any length. The MPX-90 beautifully personalizes jewelry, dog tags, key chains and pens and is among the industry's most cost effective industrial marking tools for serial number plates, data plates and more.
Designed for ease of use, the MPX-90 fits on your desktop and comes complete with design software.
The new MPX-90 includes features that allow customers with no previous experience to be able to setup and run in no time at all.


• Celebrate special occasions with unique personalized gifts your customers will cherish.
• Transform ordinary items into one-of-a-kind mementos.
• Quickly produce high-quality serial number plates at a low running cost.

Based on the Roland Photo Marking System (RPMS), the MPX-90 uses a durable diamond-tipped stylus to imprint on a wide range of surfaces including harder metals such as iron, titanium, stainless steel, gold, silver and platinum. It can also be used to imprint resins including acrylic. This innovative system strikes the surface to be marked with high speed and precision to reproduce the most delicate gradations of your original design. The MPX-90 does not burn or remove material on impact for a clean operation free of odor and debris. No daily maintenance is required.
*HV hardness of a material must not exceed 200. Some shapes cannot be imprinted. Test materials for best results.


The MPX-90 features a work area of 80mm x 80mm (3.1" x 3.1") and accepts items as thick as 40mm (1.5"). Its redesigned work table allows you to insert items of virtually any length. The MPX-90 includes a center vise to secure pens and other round items onto the work table.

The MPX-90 is a high-speed imprinting device supporting four imprinting modes: Text mode, Photo mode, High Density mode for detailed letters and illustrations, and Vector mode for linear letters and outlines. With 2.5 times the imprinting force of the previous model, the MPX-90 can imprint even the smallest text and images clearly on textured surfaces.


The MPX-90 comes with METAZA Studio, easy-to-use design software for great results. METAZA Studio accepts artwork, designs and photos from a wide variety of sources including digital cameras, mobile phones, bmp, jpg or Adobe® Illustrator® 7/8 ai or eps files. With the MPX-90, you can choose from a selection of TrueType fonts or create your own single-stroke or fill fonts. For added impact, you can wrap text around an arched line or the contours of your design. Dr. Engrave software uses variable data created in txt. or csv files to produce serial number plates for product identification and tracking.
ModelMPX-90
Imprintable Material

Gold, silver, copper, platinum, brass, aluminium, iron,stainless steel, etc. (Vickers hardness [HV] of the printing surface must be 200 or less.)

Loadable Material Size

Maximum 100 mm (w) x 200 mm (l) x 40 mm (t)
or 200 mm (w) x 100 mm (l) x 40 mm (t) ,
(3.9 in. x 7.9 in. x 1.5 in.)
or (7.9 in. x 3.9 in. x 1.5 in.)

Printing Area80 mm x 80 mm (3.1 in. x 3.1 in.)
Resolution

529 dpi (High resolution), 353 dpi (Photo), 265 dpi (Text), 1058 dpi (Vector)

Printing Direction

Unidirectional printing or bidirectional printing
(Selectable with Windows driver)

Printing Speed (Default)

50 mm/sec (1.9 in./sec) (Photo), 33 mm/sec (1.2 in./sec), (High resolution/Text), 24 mm/sec (0.94 in./sec) (Vector)

Connectivity

USB (compliant with Universal Serial Bus Specification Revision 1.1)

Power RequirementsDedicated AC adapter: AC 100V to 240V ±10% 50/60Hz
Machine: DC19V 1.6A
Power ConsumptionApprox. 24W
Acoustic Noise LevelUnder 70 dB (A)
Environment

Temperature: 10 to 30°C (50 to 86°F), Humidity: 35 to 80% (no condensation)

Dimensions286 mm (W) x 383 mm (D) x 308 mm (H) (11.3 in. (W) x 15.1 in. (D) x 12.2 in. (H))
Weight10.8 kg (23.8 lb.)
Included items

AC adapter, power cord, head caps, center vise, adhesive sheet, test-use printing material, USB cable, Roland software CD-ROM, and user's manual, etc.

System requirements for included software:METAZA Studio
Operating system *1Windows® 8/8.1 (32/64-bit)
Windows® 7 Professional/Ultimate (32/64-bit)
Windows Vista® Business/Ultimate (32/64-bit)
CPUAt least Pentium® 4 3.0 GHz or more recommended.
RAMAt least 512MB or more recommended.
Video card and monitor

At least 16 bit colors (High Color) with a resolution of 800 x 600 or more recommended.

Free hard-disk space25MB
Optical driveCD-ROM drive
*1 METAZA Studio is not compatible with Windows® RT.
